Robust and Reliable Grease Pump
Easy to use and designed to perform

The Danhydra GreaseManager is a durable, high-performing, portable filling unit optimized to stand up to the test of daily life in a wind turbine. A perfect solution for contamination free grease filling in direct WTG bearing and central lubrication system applications. The GreaseManager’s automated filling mode and the start/stop remote provides technicians with the freedom to complete other tasks while the grease pump is running. Simply load the grease cartridges, then specify the amount of grease and press start. It is light weight, easy to handle, and performs to the highest level.

  • No breakdowns due to false air in system due to patented Double Gear Pump Technology
  • Contamination free greasing system
  • Full EMC compliance
  • Highly visible screen with direct readout
  • Durable design for longevity in the field
  • Fast, reliable and easy to operate

Basically, the GreaseManager is designed to make life easier up tower when performing essential maintenance.

Applying directly in bearings or in central lubrication systems?

Do you know the difference between Automatic or Manual mode?

Get in touch to know more about the GreaseManager

Make an inquiry
High Pressure variant output max Up to 600 g. per minute
High Pressure variant recommended maximum back pressure Up to 250 bar
----
High Flow variant output max Up to 2200 g. per minute
High Flow variant recommended maximum back pressure Up to 120 bar
----
Weight 15 kg
Voltage 48 volt architecture
Remote control Yes - both variants compatible
Variants Item number
GreaseManager High Flow, 110V US ISO B 351058
GreaseManager High Flow, 110V CEE ISO B 351059
GreaseManager High Flow, 230V Schuko ISO B 351060
GreaseManager High Flow, 230V CEE ISO B 351061
GreaseManager High Flow, 110V US ISO A 351062
GreaseManager High Flow, 110V CEE ISO A 351063
GreaseManager High Flow, 230V Schuko ISO A 351064
GreaseManager High Flow, 230V CEE ISO A 351065
GreaseManager High Pressure, 110V US ISO B 351050
GreaseManager High Pressure, 110V CEE ISO B 351051
GreaseManager High Pressure, 230V Schuko ISO B 351052
GreaseManager High Pressure, 230V CEE ISO B 351053
GreaseManager High Pressure, 110V US ISO A 351054
GreaseManager High Pressure, 110V CEE ISO A 351055
GreaseManager High Pressure, 230V Schuko ISO A 351056
GreaseManager High Pressure, 230V CEE ISO A 351057

Product inquiry

Questions? You are more than welcome to get in touch to either learn more or inquire about our products. We will process your inquiry with speed.

Additional information (if possible):

Field of application

The GreaseManager is designed in two variants with both automatic and manual modes for multiple applications.

High Pressure

The High Pressure GreaseManager is used for direct lubrication applications. It is designed to continue pumping grease reliable as the back pressure increases during the direct bearing application.
The performance of the High Pressure variant is designed to provide lage amounts of grease even at 250 bar.

High Flow

The High Flow GreaseManager is designed to refill the toughest grease to your central lubrication system quickly, reducing the time required to complete the grease application.
The performance of the High Flow variant is uptimized to apply up to 2200g. per minute.

Automatic Mode

The automatic mode is reliable and adjustable. In this mode, the GreaseManager may be set to fill a specific amount of grease and shut off once that amount is reached. This frees up valuable time for the technicians to perform other important tasks while the pump is running. The remote will also work in this mode and provide the technician with the option to fill the same amount of grease in multiple applications without having to reset the GreaseManager.

Manual Mode

In manual mode the GreaseManager will pump grease until the cartridge is empty or until the technician presses the stop button. The remote provides the same start/stop option without having to be near the GreaseManager control panel.
